Installing security cameras to secure your equipment, premises, and people is ideal. Video evidence of any crime on your property can help catch the perpetrator, show where a business or home security system is vulnerable, and help you make the necessary changes so that it doesn't happen again.

1. Gather Your Tools

Prepare all necessary equipment beforehand to streamline installation. Essential items include:

  • Ladder
  • Fish tape
  • Screwdriver and screws
  • Power drill
  • Hammer

Some tools may come with your camera, but your personal, higher-quality tools can be more effective.

2. Select the Best Location

Position your camera strategically to cover key areas like entrances and minimize blind spots. Keep these tips in mind:

  • Mount it at least 10 feet high for maximum coverage and security.
  • Avoid interference from light sources.
  • Ensure proximity to a power source.
  • Choose a suitable mounting material for the surface type.

3. Mount the Camera

Secure the camera to the wall using the pre-drilled holes on the device. Steps:

  • Drill holes into the chosen surface (wood is ideal).
  • Use the mounting gear provided.

Proper placement ensures the best coverage and easier installation.

4. Run and Organize Wiring

Use the fish tape to guide cables neatly along walls for wired CCTV systems. This ensures:

  • A clean, professional appearance.
  • Safety by preventing loose or dangling wires.
  • Drill holes as needed and connect to the power source or storage device.

5. Test and Operate

Power on the CCTV system set up preferences, and test features like zoom or freeze frame. Confirm everything is functioning before packing up your tools.

Where Do You Install Security Cameras?

Common Entry Points

  • The front door, back door, and first-floor windows are the most frequently targeted entryways by most burglars.
  • Ensure CCTV cameras cover these main entrances, including front and back doors, gates, and the surrounding paths, because burglars enter these locations.

Window Surveillance

  • Monitor first-floor windows closely, as they are more vulnerable to intrusion, but observe privacy, especially on bedroom and bathroom windows.
  • To avoid trouble, cameras should also be placed at building corners to cover the entire perimeter, not on your neighbor's property or windows.

Parking Areas

  • Include driveway and garages in your surveillance plan, as these areas are prone to security risks.
  • Ensure these areas are monitored both day and night.

Field of View & Lighting

  • Carefully plan camera placement to avoid blind spots, but make sure to point cameras where there is a reasonable expectation of privacy.
  • Install cameras in well-lit areas for clearer images or infrared for motion detection and other physical security goals.

Camera Height & Visibility

  1. Mount commercial-grade security cameras at least 9 feet off the ground to prevent tampering.
  2. Decide whether cameras should be visible as a deterrent or discreet for more covert surveillance.

Basic Components of a CCTV System

Commercial Security Cameras

Commercial security cameras capture video of everything in and around a facility and then send data to recorders, monitors, and mobile devices.

Commercial camera units come in various hardware types for different camera installation service needs. Which commercial or home security cameras suit you depends on your needs, location, and budget.

IP Camera Installation Cabling

When using IP cameras—as most CCTV systems do these days—you will most likely be looking at Cat5E or Cat6 cables. These ethernet cables can transfer the large amount of data required by digital and high resolutions at breakneck speeds, often over long distances.

Network Video Recorder (NVR)

The Network Video Recorder, also known as the NVR, is another essential element of an IP camera. Connected to the same IP network, the network video recorder can be installed virtually anywhere in your building or home.

Hard Drives

An NVR makes it easy to record videos, but you will need connected hard drives to store this video.

Choosing the right amount of facility for your surveillance camera installation can seem like a confusing gamble, but it doesn't have to be; it's simply a matter of calculating the length of video you need to store by the bitrate and resolution your camera shoots at.

Which is Better, DVR or NVR?

DVRs with coaxial cables generally have image quality that deteriorates after around 300 feet. With an NVR system, you can get around this by using a POE extender, POE injector, or POE switch to extend cables over long distances while maintaining high image quality.

NVRs offer high flexibility. They are connected to the same IP network and can be installed virtually anywhere in a building.

Since NVRs use software programs to record video automatically in digital format, they can easily transmit data over computer networks and even view a security camera remotely in real time on a mobile device.

FAQs

Why do establishments need business surveillance camera installation?

Businesses need surveillance camera installation because surveillance cameras provide evidence of incidents, helping catch perpetrators and enhance security.

Commercial security camera systems also reveal vulnerabilities, allowing preventive measures. Monitoring your property provides insights into areas where security measures may be lacking or require enhancement.

This proactive approach allows businesses to take preventive measures, fortify their security protocols, and minimize the risk of future incidents.

Why are CCTV cameras provided for commercial installation?

CCTV cameras are provided for commercial installations because they enhance security by deterring potential criminals and capturing evidence in case of incidents.

Commercial and home security cameras also help monitor and manage day-to-day operations, ensuring safety and efficiency in commercial settings.

In essence, CCTV cameras provide an all-encompassing solution that bolsters surveillance system security and promotes productivity and safety in commercial environments.

What are the requirements for commercial surveillance camera installation?

Commercial surveillance camera installation requires cameras, cabling (Cat5e/Cat6), a Network Video Recorder (NVR) for recording, power outlet (PoE or other), mounts, power adapter, a robust network, professional installation, legal compliance, and a maintenance plan to ensure the functionality of commercial security camera systems and compliance with regulations.

Conclusion

Commercial security camera installation companies have experts who can ensure cameras are positioned at the right angle and use a suitable drill bit to drill holes, providing a safe and effective way to install security cameras without fail for business protection.
